The robust TERRA PC Mini V5 equipped with an Intel Core i3 (10th generation) and a fast PCIe SSD makes it even faster than the previous generations.

This device is supporting 4K-UHD, Dual-Monitor- Support, and 24/7 long-term usage. It is ideal for Digital-Signage- and Point-Of-Sale-Applications.

With the optional purchasable VESA mount, you can easily assemblage the device to a TFT display.

• Processor model: Intel Core i3 (10. Gen.) 10100 / 3.6 GHz (6 MB SmartCache, up to 4.3 GHz with Intel Turbo Boost Technology)
• Operating system: Windows 11 Pro
• Processor family: Core i3
• Processor cores: Quad-Core (4 Core)
• Processor socket: FCLGA1200 Socket
• Number of processors: 1
• Internal memory: 8 GB
• Memory layout (slots x size): 1 x 8 GB
• Maximum internal memory: 32 GB
• Memory clock speed: 3200 MHz
• Internal memory type: DDR4
• Memory slots: 2 pc(s)
• Memory form factor: SO DIMM, 260-PIN
• Total storage capacity: 250 GB
• HDD interface: 1x S-ATA-3 für 1x 2,5" max. 12.5mm high
  1x M.2-2280 SATA-3 (6 Gbit/s)/ PCIe Gen 2.0 x4 NVMe
  Supports M.2 SSDs Typ 2242, 2260, 2280 mit SATA or PCIe
• RAID levels: No Raid support
• Card reader integrated: Not available
• SSD Interface: PCIe (NVMe)
• SSD capacity: 250 GB
• HDD capacity: 1 x 250 GB - SSD Samsung
• Number of storage drives supported: 2
• Storage media: SSD M.2
• Series: Business
• Noise level: 22 dB
• Motherboard chipset: Intel H410 Express
• Chassis type: Mini format
• Certification: ISO 9001, Assembled in Germany
• Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN60950, EN55022,EN55024, EN61000-3-2/3, 89/336/ECC
  24-7 ready (temporary fan-maintance required)
• Keyboard form factor: Optional
• Expansion: slots 1x M.2 Type 2242/ 2260/ 2280 (PCIe x4 NVMe/ SATA)
  1x M.2-2230E (used by WiFi/ BT module)
• Height: 4.3 cm
• Width: 18 cm
• Depth: 19 cm
• Weight: 1240 g
• Interface:
  Front 1x USB 3.1 Gen1 Type A, 1x USB 3.1 Gen1 Type C, 2x USB 2.0 Type A, Line-out, Mic-in
  Rear: 2x USB 3.1 Gen1 Type A, 2x USB 2.0, 1x HDMI, 1x Display Port (DP)
  2x RS232 (COM) Port, 9-pol. D-Sub (5/12V, 1x RS422/RS485), 2x RJ45, DC-In
• Compatible operating systems: Windows 10
• Cooling type: Heatpipe-Processor-cooling. Two 60-mm-fans at top
• Special features: Kensington Lock, Supports PowerOn after Power loss
  Option: VESA Mounting Kit 75x75 mm/ 100x100 mm
  TPM 2.0
• Mouse included: Optional
• Graphics adapter ports: 1x HDMI, 1x DP (Display Port), Supports Dual-Monitoring
• On-board graphics adapter memory: Dynamic
• On-board graphics adapter maximum resolution: HDMI up to 3840x2160 @ 30Hz (4K), DP up to 3840x2160 @ 60Hz (4K)
• Graphics adapter: Intel UHD Graphics 630 (1100 MHz)
• On-board graphics adapter model: Intel UHD Graphics 630 (1100 MHz)
• Power source: External fanless power supply
  Efficiency : > 87%
• Power consumption (standby): Ø 0.50 Watt (S3 Mode. Suspend to RAM
  0.15 Watt Soft off (S5 Mode) W
• Maximum input power: 90 Watt
• Nominal power: Ø 10 Watt Long Idle-Mode
  Ø 45 kWh a year (TEC = Typical Energy Consumption)
• AC adapter input voltage: AC 100/240 V ( 50/60 Hz )
• Operating temperature (T-T): 5 °C - 50 °C
  Note: In environments with an operating temperature above 40°, SSD-drives and SO-DIMM-memories with an advanced range of temperature are recommended!
• Maximum operating temperature range (T-T): 50 °C
  Note: In environments with an operating temperature above 40°, SSD-drives and SO-DIMM-memories with an advanced range of temperature are recommended!
• Recommended humidity operating range: 10 - 80% (non-condensing)
• Ethernet LAN: Network adapter - integrated
• LAN controller: 2x Realtek RTL8111G, WOL/ PXE
  Supports Teaming
• Wi-Fi standards: Intel 9260 WiFi/BT module integrated via M.2 (2230E)
  2x portable external antennas
  802.11b/g/n/ac
  Bands: 2.4 GHz + 5 GHz (Dual-Band)
• Data link protocols: thernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
• Bluetooth: 5.0
• Optical drive type: None
