Promethean ActivSuite
With our new software, your favourite ActivPanel engagement apps are accessible on your device to use at and away from the panel. Hello, enhanced freedom and flexibility!
An industry-leading display
Get the full picture with reduced reflection, every-angle views, highly accurate colour, and true-black contrast thanks to optical bonding, QLED, and FALD1. All that, and it saves energy.
High tech, low footprint
ActivPanel 10 is Energy Star Certified, durably designed, consumes less power2, and comes with less packaging.
Picture-in-picture
Easily integrate media and play videos in a small window while continuing to use other windows.
Full Array Local Dimming (FALD)
An industry-leading display, true black and high contrast visuals provide a clearer, more vibrant image.
8-array mic and speakers
Boost participation by using the panel’s built-in soundbar and 8-array mic.
Display
Â
With our new software, your favourite ActivPanel engagement apps are accessible on your device to use at and away from the panel. Hello, enhanced freedom and flexibility!
An industry-leading display
Get the full picture with reduced reflection, every-angle views, highly accurate colour, and true-black contrast thanks to optical bonding, QLED, and FALD1. All that, and it saves energy.
High tech, low footprint
ActivPanel 10 is Energy Star Certified, durably designed, consumes less power2, and comes with less packaging.
Picture-in-picture
Easily integrate media and play videos in a small window while continuing to use other windows.
Full Array Local Dimming (FALD)
An industry-leading display, true black and high contrast visuals provide a clearer, more vibrant image.
8-array mic and speakers
Boost participation by using the panel’s built-in soundbar and 8-array mic.
Display
- Screen Size and Resolution: 65" 4K; UHD (3840 x 2160 @ 60 Hz) 75" 4K; UHD (3840 x 2160 @ 60 Hz) 86" 4K; UHD (3840 x 2160 @ 60 Hz)
- Backlight Technology: Direct LED Backlight
- Screen Type: TFT LCD
- Blue Light Reduction: Yes
- Bonded Glass: Yes
- Aspect Ratio: 16:9
- Display Area: 65": 1431 x 807 mm (56.3 x 31.8 in) 75": 1653 x 931 mm (65.1 x 36.7 in) 86": 1898 x 1069 mm (74.7 x 42.1 in)
- Display Colors: 1.07 Billion (10-bit)
- LCD Viewing Angle: 178°
- LCD Response Time: 8 ms
- LCD Refresh Rate (Panel): 60 Hz
- LED Lifespan: 50,000 hours
- Contrast Ratio: 5000:1 Dynamic 1200:1 Static
- Typical Max. Brightness: 65": 520 cd/m2, 75": 500 cd/m2, 86": 565 cd/m2
- Ambient Light Sensor: Yes
- Glass Hardness: 9H (pencil) , 7 (Mohs)
- Glass type: Heat tempered
- Glass Thickness: 3.2 mm
- Glass Coating: Anti-Glare, Anti-Fingerprint, Anti-Smudge
- Operating System: No OS - Secure by Design
- Compatible Promethean Devices: OPS-M, OPS-A, Chromebox
- Dual Front-facing Speakers: 2 x 20 W
- Vellum Touch Technology: Yes
- Contimous Touch Points: 40
- Touch Resolution: 32768 x 32768 px
- Touch Response Time: 3 ms
- Touch Accuracy: >1 mm
- Scan Rate: 500 Hz
- Gestures and Edge Swipes: Windows® supported
- Unique Pens IDs: 3
- Pen and Touch Differentiation: Yes
- Palm Erase: Yes
- Palm Rejection: Yes
- Writing-hand Palm Rejection: Yes
- Pens Included: 2 x Passive battery-less pens
- Pen Holder: Integrated
- Pen Tip Diameter: 3 mm
- Pen Eraser Diameter: 7 mm
- Integrated Active Pen Charging: Active Pen Ready
- Touch Enabled PiP: Yes
- Compatibility: Windows® 10 and 11; macOS® Ventura 13 and Sonoma 14; Linux® Ubuntu 22.04 to 24.04 LTS; ChromeOSTM; Android 14
- OPS Slot: 1
- HDMI In(Rear): 2 x 2.1
- Display Port: 1 x 1.4
- USB-A(Rear): 3 x 3.2 Gen 1
- USB-A (Rear): 1 x 2.0
- USB-B(Touch, Rear): 3 x 3.0
- USB-C (Rear): 1 x 3.2 Gen 1 (100 W Power Delivery)
- USB-A (Front): 1 x 3.2 Gen 1
- USB-C (Front): 1 x 3.2 Gen 1
- HDMI Out: 1 x 2.0
- LAN In (RJ45): 10/100/1000
- LAN Out (RJ45): 10/100/1000
- Wake-on-LAN: Yes
- S/PDIF: Optical
- Audio Out (3.5 mm): 1
- Serial (RS232): 1
- Power Requirements: 100 V - 240 V AC
- Max. Energy Star Reported Luminance 450 cd/m2: 65": 122 W 75": 147 W 86": 176 W
- Power Consumption (Standby): <= 0.5 W
- Ultra-quiet Fanless Design: Yes
- Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperature: -15 °C to 55 °C
- Operating Humidity: 20% to 80% non-condensing humidity
- Storage Humidity: 20% to 90% non-condensing humidity
- Panel Dimensions: 65": 1484 x 107 x 931 mm (58.4 x 4.2 x 36.7 in) 75": 1705 x 107 x 1056 mm (67.1 x 4.2 x 41.6 in) 86": 1950 x 107 x 1194 mm (76.8 x 4.2 x 47 in)
- Panel Net Weight: 65": 37.8 kg (83.3 lbs) 75": 50.7 kg (111.8 lbs) 86': 62.9 kg (138.7 lbs)
