'Build to Order'
| General | |
| Processor model | Intel Core i7 (13. Gen.) 13700KF / 30 MB Intel Smart Cache, up to 5.4 GHz with Intel Turbo Boost Technology |
| Processor | |
| Processor family | Core i7 |
| Processor cores | 16-Core |
| Processor socket | FCLGA1700 Socket |
| Number of processors | 1 |
| Memory | |
| Internal memory | 32 |
| Memory layout (slots x size) | 2 x 16 GB |
| Maximum internal memory | 128 GB |
| Memory clock speed | 6000 MHz |
| Internal memory type | DDR5 SDRAM |
| Memory slots | 4 pc(s) |
| Memory form factor | DIMM, 288-PIN |
| Storage | |
| Total storage capacity | 1 TB |
| HDD interface | 2x M.2_1 slot (Key M), type 2242/2260/2280/22110 (PCIe 4.0 x4 mode) 2x M.2_2 slot (Key M), type 2242/2260/2280 (PCIe 4.0 x4 mode) |
| RAID levels | RAID 0 RAID 1 RAID 5 RAID 10 |
| SSD interface | PCIe 4.0 |
| SSD capacity | 1 TB |
| HDD capacity | 1 x 1 TB - SSD |
| Storage media | SSD M.2 |
| Performance | |
| Series | Gamer |
| Audio output channels | 8-channel |
| Motherboard chipset | Intel Z790 |
| Design | |
| Chassis type | Mid tower |
| Certification | ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC |
| Keyboard form factor | Option. Keyboard not included |
| Keyboard | |
| Connectivity technology | Wired |
| Device interface | USB |
| Technical details | |
| Localization | German |
| Packaging content | |
| Included Accessories | Quick Start Guide, Powercord EU |
| Keyboard language | Option. Keyboard not included |
| Expansion slots | |
| Expansion slots | 1x PCIe 5.0/4.0/3.0 x16, 1x PCIe 4.0 x16 slot (supports x4 mode), 1x PCIe 4.0 x4 slot 2x PCIe 3.0 x1 |
| Weight & dimensions | |
| Height | 44.3 cm |
| Width | 23.2 cm |
| Depth | 45.0 cm |
| Weight | 11.5 kg |
| Other features | |
| Number of drive bays | 2 intern - 8.9 cm ( 3.5"/ 2.5" mit Adapter) 5 intern 6.4 cm (2.5" SSD) |
| Interface | 1x USB 3.2 Gen 2x2 port (1x USB Type-C®), 3x USB 3.2 Gen 2 ports (2x Type-A + 1x USB Type-C®), 4x USB 3.2 Gen 1 ports (4x Type-A), 1x DisplayPort, 1x HDMI, 1x Wi-Fi Module, 1x Intel 2.5Gb 5x Audio jacks, 1x Optical S/PDIF out port |
| Compatible operating systems | Windows 10, Windows 11 |
| Motherboard manufacturer | ASUS TUF GAMING Z790-PLUS WIFI |
| Cooling type | Cooler Master MasterLiquid 240L Core ARGB |
| Special features | Mesh Front Panel Tempered Glass Side Panel |
| Mouse | |
| Mouse included | yes |
| Graphics | |
| On-board graphics adapter memory | 12 GB GDDR6X |
| On-board graphics adapter maximum resolution | Max. 7680 x 4320 |
| Graphics card | MSI VGA RTX4070 SUPER 12G VENTUS 2X OC 3xDP/HDMI |
| Graphics adapter ports | 1x HDMI, 3x DP (Display Port) |
| Power | |
| Power source | Power supply ATX 80 plus Energy Efficiency typial: >= 85% |
| Power consumption (standby) | Ø 1.9 Watt (Sleep Mode S3, Suspend to RAM, WOL activated) 0,25 Watt Soft off (S5 Mode) |
| Maximum input power | 850 W |
| Nominal power | Ø 39 Watt Idle-Mode Ø 167 kWh a year (TEC = Typical Energy Consumption) |
| Operational conditions | |
| Operating temperature (T-T) | 5 °C - 35 °C |
| Recommended humidity operating range | 10 - 75% (non-condensing) |
| Network | |
| Ethernet LAN | RJ45 |
| LAN controller | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps, WOL/PXE |
| Wi-Fi standards | Wi-Fi 6E, 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax), Supports 2.4/5/6 GHz Bluetooth 5.3 |
| Data link protocols | Ethernet Fast Ethernet Gigabit Ethernet 2.5 Gb Ethernet |
| Optical drive | |
| Optical drive type | Without optical drive |
| Input device | |
| Movement detection technology | Optical |
| Device interface | USB Note: Keyboard not included |
