‘Build to Order’
| General | |
| Processor model | AMD Ryzenâ„¢ 7 5800X Processor, (8C/16T, 36 MB Cache, 4.7 GHz Boost) AMD Ryzen 5 7600X / up to 5.3 GHz, 6-C/ 12T, 32 MB L3-Cache |
| Operating system | Windows 11 Pro |
| Software | |
| Pre-installed software | 1 month trial version for new Microsoft® 365 user |
| Processor | |
| Processor family | AMD Ryzen 5 |
| Processor cores | 14-Core |
| Processor socket | AM5 |
| Number of processors | 1 |
| Memory | |
| Memory layout (slots x size) | 2 x 16 GB |
| Maximum internal memory | 256 GB |
| Internal memory type | DDR5 SDRAM |
| Memory slots | 4 pc(s) |
| Storage | |
| Total storage capacity | 500 GB 1 TB |
| HDD interface | 4 x SATA-3 (6 Gb/s) |
| RAID levels | RAID 1 RAID 10 |
| Card reader integrated | Not available |
| SSD interface | PCIe 4.0 |
| SSD capacity | 1 TB |
| Number of storage drives supported | 4 x SATA-3 (6 Gb/s) 3 x M.2 1 x U.2 |
| Storage media | SSD M.2 |
| Performance | |
| Series | Workstation |
| Noise level | 25.9 dBA |
| Audio output channels | 5.1 HD Audio Codec |
| Motherboard chipset | AMD TRX50 |
| Design | |
| Chassis type | Tower |
| Certification | ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN60950, EN55022,EN55024, EN61000-3-2/3, 89/336/ECC |
| Keyboard form factor | Optional |
| Keyboard | |
| Keyboard language | International |
| Device interface | USB |
| Technical details | |
| Localization | International |
| Field of use | AutoCad Inventor Revit Autodesk 3ds Max Autodesk Maya Adobe Illustrator Autodesk AutoCAD |
| Packaging content | |
| Included Accessories | Manual (DE/ EN/ FR/ PL), powercord EU |
| Weight & dimensions | |
| Width | 23.2 cm |
| Depth | 45.0 cm |
| Other features | |
| Number of drive bays | 1 front - 13.3 cm ( 5.25" ) 4 internal - 8.9 cm ( 3.5"/ 2.5" with Adapter) 5 internal 6.4 cm (2.5" SSD) |
| Compatible operating systems | Windows 10, Windows 11 |
| Cooling type | Active |
| Compliance industry standards | CE, ISO 9001, Assembled in Germany Compatibility: PC2001, SMBios (DMI) 2.3, PCI 2.2,WFM 2.0, EnergyStar, EN60950, EN55022,EN55024, EN61000-3-2/3, 89/336/ECC |
| Mouse | |
| Mouse included | TERRA wheel mouse optical |
| Graphics | |
| On-board graphics adapter memory | 5 GB |
| On-board graphics adapter maximum resolution | Digital Max Resolution: 5120x2880 |
| Graphics card | NVIDIA Quadro P2200 |
| On-board graphics card model | PCI Express - plug-in-card - active cooling - single slot NVIDIA Quadro P2000 |
| Graphics adapter ports | 4x Display Port (DP) 4x Display Port (DP 1.4) |
| Power | |
| Power source | ATX Power Supply 80 Plus Gold, 24-7 Continuous Operation Energy efficiency (Workload 20 %/ 50 % / 100 %): 87 %/ 90 % / 87 % |
| Maximum input power | 650 Watt |
| Nominal power | Ø 50 Watt Idle-Mode Ø 176 kWh a year (TEC = Typical Energy Consumption) |
| AC adapter input voltage | AC 100/240 V ( 50/60 Hz ) |
| Operational conditions | |
| Operating temperature (T-T) | 10 °C - 35 °C |
| Maximum operating temperature range (T-T) | 35 °C |
| Recommended humidity operating range | 10 - 75% (non-condensing) |
| Network | |
| Ethernet LAN | Network adapter integrated |
| LAN controller | Marvell AQtion 10GB Intel I226-LM 2.5GB |
| Data link protocols | Ethernet Fast Ethernet Gigabit Ethernet |
| Optical drive | |
| Optical drive type | Without optical drive |
| Input device | |
| Movement detection technology | Optical |
| Device interface | USB |
