'Build to Order'
| General | |
| Operating system | Windows 11 Pro |
| Software | |
| Pre-installed software | 1 month trial version for new Microsoft® 365 user |
| Processor | |
| Processor family | Core i7 |
| Processor cores | 12-Core |
| Number of processors | 1 |
| Memory | |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 1 x 16 GB |
| Maximum internal memory | 64 GB |
| Memory clock speed | 3200 MHz |
| Internal memory type | DDR4 |
| Memory slots | 2 pc(s) |
| Storage | |
| Total storage capacity | 500 GB |
| HDD interface | 1x PCIe Gen4 x 4 /SATA M.2 2280 slot |
| RAID levels | No RAID supported |
| SSD interface | PCIe (NVMe) |
| SSD capacity | 500 GB |
| HDD capacity | 1 x 500 GB - SSD |
| Number of storage drives supported | 1 |
| Storage media | SSD M.2 |
| Performance | |
| Series | Business Medical |
| Design | |
| Chassis type | Micro format |
| Certification | ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC |
| Keyboard form factor | Optional |
| Technical details | |
| Localization | International |
| Packaging content | |
| Included Accessories | Quick Start Guide, Power supply, powercord EU, VESA mounting kit |
| Weight & dimensions | |
| Height | 4.83 cm |
| Width | 13.91 cm |
| Depth | 13.42 cm |
| Weight | 465 g |
| Other features | |
| Interface | Front :1x USB 3.2 Gen2 Type C, 3x USB 3.2 Gen2 Type A, 1x Audio Rear: 1x HDMI(2.1), 1x HDMI(2.0b), 1x Mini-DP (mDP) 1x USB 4.0 (Supports Intel Thunderbolt 4 with DP mode)*, 2x USB 2.0 1x RJ45, DC-in, Kensington Lock |
| Compatible operating systems | Windows 10, Windows 11 |
| Cooling type | Active |
| Compliance industry standards | This appliance is classified as a Class B information technology equipment (ITE) and is intended primarily for use in residential and office environments. The CE mark confirms conformity with the following EU directives: (1) EMC Directive 2004/108/EC Electromagnetic Compatibility (2) Low Voltage Directive 2006/95/EC Electrical equipment designed for use within certain voltage limits. |
| Special features | TPM 2.0 Secure Boot Windows Autopilot-ready |
| Mouse | |
| Mouse included | Optional |
| Graphics | |
| On-board graphics adapter memory | Dynamisch GB |
| On-board graphics adapter maximum resolution | HDMI 2.1 max. 7680 x 4320@60Hz HDMI 2.0a max. 3840 x 2160@60Hz MiniDP 1.4a max. 3840 x 2160@60Hz USB 4.0 Type-C DP supports DP1.4a max. 3840x2160@60Hz* |
| Graphics card | Intel Iris Xe Graphics |
| On-board graphics card model | Integrated |
| Graphics adapter ports | 2x HDMI, 1x mDP Supports Triple-Monitoring |
| Power | |
| Power source | External fanless power supply |
| Power consumption (standby) | Ø 2.5 Watt (S3 Mode, Suspend to RAM, WOL activated) 0,30 Watt Soft off (S5 Mode) |
| Maximum input power | 135 W |
| Nominal power | Ø 15 Watt Long Idle-Mode Ø 67 kWh a year (TEC = Typical Energy Consumption) Further information regarding Energy consumption see https://www.wortmann.de/green and/ or Quicklinks for this product (if available) |
| AC adapter input voltage | AC 100/240 V ( 50/60 Hz ) |
| Operational conditions | |
| Operating temperature (T-T) | 5 °C - 35 °C |
| Maximum operating temperature range (T-T) | 35 °C |
| Recommended humidity operating range | 10 - 75% (non-condensing) |
| Network | |
| Ethernet LAN | Network adapter integrated |
| LAN controller | Intel® Ethernet Controller i225-V |
| Wi-Fi standards | Intel® Wi-Fi 6E AX211(Gig+) |
| Data link protocols | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax Bluetooth 5.2 |
| Optical drive | |
| Optical drive type | Without optical drive |
| Input device | |
| Device interface | USB Note: Keyboard not included |
| Notes | |
| Additional Information | * Wortmann AG doesn't support 4-Port Display Mode |
